Ferrous & Non-Ferrous Stock Grades

​Scot Forge produces guaranteed sound-centered round, square, hex or flat forged steel bars of weights up to 100,000 lbs. in ferrous and non-ferrous materials for a variety of applications, such as Aerospace, Defense, Infrastructure, Mining, Nuclear, Oil & Gas, Heavy Industrial Equipment and Power Generation. With no minimums for stocking grades, Scot Forge will help you deliver whether you need one bar or a truckload.

pattern (1).jpg

Ferrous & Non-Ferrous Stock Grades

​Scot Forge produces guaranteed sound-centered round, square, hex or flat forged steel bars of weights up to 100,000 lbs. in ferrous and non-ferrous materials for a variety of applications, such as Aerospace, Defense, Infrastructure, Mining, Nuclear, Oil & Gas, Heavy Industrial Equipment and Power Generation. With no minimums for stocking grades, Scot Forge will help you deliver whether you need one bar or a truckload.

4340 VAR      E4340      4330 VAR      E4330      4330 MOD      300M

9310 VAR      SAE9310           15-5PH VAR      17-4PH VAR

AMS 2300      AMS 5622      AMS 5659       ASM 6411      AMS 6414

AMS6417      AMS 6419       AMS 6257       AMS 6265





*More may be available upon request.  Contact a Bar Team Specialist  for more information

1010        1035        1141        1018        1040        1146        1020

1050       1541V      1021      1055      15B22      1022       1060

3310      1026      1070       4130      1029       1080       4130API

1030      1117      4140

A182F11        A182F22        A336F1        A336F22A         A350FL2

A350LF3        Nitralloy "N"         Nitralloy 135         H13

*More may be available upon request.  Contact a Bar Team Specialist  for more information

Forged Bar Capabilities

Guaranteed sound-centered bars up to 100,000 lbs.

Round bars form 3" to 65" diameter

Tartan Bars 6" to 16" diameter

Square bars to 65" square

Hex bars to 65" across the flats

Flat bars up to 90" wide

Minimum 3-to-1 reduction

Maximum length: 700"

Forged Bar Products

Forged Bar Capabilities

Guaranteed sound-centered bars up to 100,000 lbs.

Round bars form 3" to 65" diameter

Tartan Bars 6" to 16" diameter

Square bars to 65" square

Hex bars to 65" across the flats

Flat bars up to 90" wide

Minimum 3-to-1 reduction

Maximum length: 700"

Plaid Angle Red.png

SURFACE CONDITIONS AVAILABLE

Surface

Stock Allowance

Size Tolerance

Fin

Precision Forged

1/2" to 3/4" over finish size

+/- 1/8"

Forged surface, no RMS

Forged and Rolled

3/8" over finish size

+3/8", -0

hot-rolled surface

Rough Machined

1/4" over finish size

+/- 1/16"

500 RMS or better

Peeled

1/4" over finish size

+ 1/32", -0

125 to 250 RMS

Turned and Polished

To finish size

+0, -0.008"

63 RMS

Plaid Angle Red.png

SURFACE CONDITIONS AVAILABLE

Stock Allowance

Stock Allowance

Size Tolerance

Finish

Precision Forged

1/2" to 3/4" over finish size

+/- 1/8"

Forged surface, no RMS

Forged and Rolled

3/8" over finish size

+3/8", -0

hot-rolled surface

Rough Machined

1/4" over finish size

+/- 1/16"

500 RMS or better

Peeled

1/4" over finish size

+ 1/32", -0

125 to 250 RMS

Turned and Polished

To finish size

+0, -0.008"

63 RMS

Our Clinton, WI, plant specializes in round bars and has dedicated planishing, cutting, heat treating, straightening, machining and testing equipment to ensure consistent high quality and fast turnaround times. Our Tartan Bars are manufactured through a combination of the forging and planishing process. The result is unique to our industry—bars with a forged sound center, rolled bar surface quality and extremely tight dimensional tolerances.

Shipped Direct To Your Dock

Get your quote for 6"-16" bar from an industry specialist today!

Our Clinton, WI, plant specializes in round bars and has dedicated planishing, cutting, heat treating, straightening, machining and testing equipment to ensure consistent high quality and fast turnaround times. Our Tartan Bars are manufactured through a combination of the forging and planishing process. The result is unique to our industry—bars with a forged sound center, rolled bar surface quality and extremely tight dimensional tolerances.

Shipped Direct To Your Dock

Get your quote for 6"-16" bar from an industry specialist today!

Scot Forge’s Tartan Bars feature a fully consolidated forged center, and a surface that is finished by multiple-pass rolling. Combining forging and rolling cuts press time in half; produces short runs in short order.

Plaid Angle Red.png

Scot Forge Difference

At Scot Forge, we know the importance of getting your parts on-time, as expected. However, for customers new to procuring forgings, ordering a forging that will meet all specifications for end-use applications may be a challenge, which is why finding a trusted supplier and partner is essential. Our employee-owners are here to ensure your project stays on track with our forgings by offering:

Quality Assurance

Scot Forge is proud to be ISO 9001:2015 and AS9100D  certified, and our team is committed to providing outstanding customer satisfaction. Further pursuance of aerospace products has led to NADCAP accreditation in both Heat Treatment for nickel material and Nondestructive Testing.

Every Scot Forge customer gets placed with a qualified team that will guide each nickel forging delivered from the inquiry stage to order placement, expediting and shipping.

We offer many size forgings in both standard and unique geometries to meet your needs.
